Razor XR-7 Equipment Specs

Equipment Specs

UTILITY & SPECIFICATIONS

Wall Mount

Free Standing Frame

Utilities

WALL MOUNT WASH

BAY DIMENSIONS

FREE STANDING FRAME WASH BAY

DIMENSTIONS & SPECIFICATIONS

UTILITY

REQUIREMENTS

WALL MOUNT

Wall Mount Wash Bay Dimensions

HOW TO MEASURE:

Minimum dimensions are from nearest inside obstructions entrance to exit, and bay floor to ceiling, e.g. door tracks, counterweights, etc. Add in additional length for these items.

HEIGHT

OPTIONS

BAY WIDTH: 13' 4" - 16' 9"

OPTIONS

BAY WIDTH: 16' 9" - 18' 0"

MIN

10' 4" (3150 mm)

MIN

11' 4" (3453 mm)

MAX

n/a

MAX

n/a

PREFERRED

12' (3658 mm)

PREFERRED

12' (3658 mm)

WIDTH

STANDARD

RAILS: 27' 4" (8331 mm)

ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

13' 4" (4064 mm)

MIN

13' 4" (4064 mm)

MIN

13' 4" (4064 mm)

MAX

18' (5486 mm)

MAX

18' (5486 mm)

MAX

18' (5486 mm)

PREFERRED

15' (4572 mm)

PREFERRED

15' (4572 mm)

PREFERRED

15' (4572 mm)

LENGTH

OPTIONAL

RAILS: 25' 4" (7722 mm)

NO DRYER

RAILS: 27' 4" (8331 mm)

WASH & DRYER W/ COVERS

RAILS: 27' 4" (8331 mm)

RAILS W/ ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

25' 8" (7823 mm)

MIN

27' 8" (8432 mm)

MIN

31' 4" (9550 mm)

MIN

31' 4" (9550 mm)

MAX

n/a

MAX

n/a

MAX

n/a

MAX

n/a

PREFERRED

28' (8534 mm)

PREFERRED

30' (9144 mm)

PREFERRED

42' (12802 mm)

PREFERRED

42' (12802 mm)

HEIGHT

OPTIONS

BAY WIDTH: 13' 4" - 16' 9"

MIN

10' 4" (3150 mm)

MAX

n/a

PREFERRED

12' (3658 mm)

OPTIONS

BAY WIDTH: 16' 9" - 18' 0"

MIN

11' 4" (3453 mm)

MAX

n/a

PREFERRED

12' (3658 mm)

WIDTH

STANDARD

RAILS: 27' 4" (8331 mm)

MIN

13' 4" (4064 mm)

MAX

18' (5486 mm)

PREFERRED

15' (4572 mm)

ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

13' 4" (4064 mm)

MAX

18' (5486 mm)

PREFERRED

15' (4572 mm)

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

13' 4" (4064 mm)

MAX

18' (5486 mm)

PREFERRED

15' (4572 mm)

LENGTH

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

25' 8" (7823 mm)

MAX

n/a

PREFERRED

28' (8534 mm)

NO DRYER

RAILS: 27' 4" (8331 mm)

MIN

27' 8" (8432 mm)

MAX

n/a

PREFERRED

30' (9144 mm)

WASH & DRYER W/ COVERS

RAILS: 27' 4" (8331 mm)

MIN

31' 4" (9550 mm)

MAX

n/a

PREFERRED

42' (12802 mm)

RAILS W/ ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

31' 4" (9550 mm)

MAX

n/a

PREFERRED

42' (12802 mm)

FLOOR MOUNT

Free Standing Frame Wash Bay Dimensions

HOW TO MEASURE:

Minimum dimensions are from nearest inside obstructions entrance to exit, and bay floor to ceiling, e.g. door tracks, counterweights, etc. Add in additional length for these items.

HEIGHT

STANDARD

RAILS: 27' 4" (8331 mm)

ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

10' 9" (3277 mm)

MIN

10' 9" (3277 mm)

MIN

10' 9" (3277 mm)

MAX

n/a

MAX

n/a

MAX

n/a

PREFERRED

11' (3353 mm)

PREFERRED

11' (3353 mm)

PREFERRED

11' (3353 mm)

WIDTH

STANDARD

RAILS: 27' 4" (8331 mm)

ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

13' 8" (4166 mm)

MIN

13' 8" (4166 mm)

MIN

13' 8" (4166 mm)

MAX

n/a

MAX

n/a

MAX

n/a

PREFERRED

14' 4" (4369 mm)

PREFERRED

14' 4" (4369 mm)

PREFERRED

14' 4" (4369 mm)

LENGTH

OPTIONAL

RAILS: 25' 4" (7722 mm)

NO DRYER

RAILS: 27' 4" (8331 mm)

WASH & DRYER W/ COVERS

RAILS: 27' 4" (8331 mm)

RAILS W/ ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

25' 8" (7823 mm)

MIN

27' 8" (8432 mm)

MIN

31' 4" (9550 mm)

MIN

31' 4" (9550 mm)

MAX

n/a

MAX

n/a

MAX

n/a

MAX

n/a

PREFERRED

28' (8534 mm)

PREFERRED

30' (9144 mm)

PREFERRED

42' (12802 mm)

PREFERRED

42' (12802 mm)

HEIGHT

STANDARD

RAILS: 27' 4" (8331 mm)

MIN

10' 9" (3277 mm)

MAX

n/a

PREFERRED

11' (3353 mm)

ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

10' 9" (3277 mm)

MAX

n/a

PREFERRED

11' (3353 mm)

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

10' 9" (3277 mm)

MAX

n/a

PREFERRED

11' (3353 mm)

WIDTH

STANDARD

RAILS: 27' 4" (8331 mm)

MIN

13' 8" (4166 mm)

MAX

n/a

PREFERRED

14' 4" (4369 mm)

ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

13' 8" (4166 mm)

MAX

n/a

PREFERRED

14' 4" (4369 mm)

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

13' 8" (4166 mm)

MAX

n/a

PREFERRED

14' 4" (4369 mm)

LENGTH

OPTIONAL

RAILS: 25' 4" (7722 mm)

MIN

25' 8" (7823 mm)

MAX

n/a

PREFERRED

28' (8534 mm)

NO DRYER

RAILS: 27' 4" (8331 mm)

MIN

27' 8" (8432 mm)

MAX

n/a

PREFERRED

30' (9144 mm)

WASH & DRYER W/ COVERS

RAILS: 27' 4" (8331 mm)

MIN

31' 4" (9550 mm)

MAX

n/a

PREFERRED

42' (12802 mm)

RAILS W/ ON-BOARD DRYER

RAILS: 30' 4" (9246 mm)

MIN

31' 4" (9550 mm)

MAX

n/a

PREFERRED

42' (12802 mm)

UTILITY

Utility Requirements

AIR:

100 PSI @ 11 SCFM (6.89 bars @ 311 l/m) includes optional Tri-Color foam

WATER:

25 GPM @ 35 PSI (94.6 l/m @ 2.4 bars) minimum at pump station

ELECTRIC:

208/230 VAC, 3 PH, 60 Hz (Five wire, three phase with neutral and ground)

AIR:

WATER:

ELECTRIC:

100 PSI @ 11 SCFM (6.89 bars @ 311 l/m) includes optional Tri-Color foam

25 GPM @ 35 PSI (94.6 l/m @ 2.4 bars) minimum at pump station

208/230 VAC, 3 PH, 60 Hz (Five wire, three phase with neutral and ground)

VOLTAGE: 208

PLACEHOLDER

VOLTAGE: 230

PLACEHOLDER

VOLTAGE: 380/ 415 (50 Hz)

VOLTAGE: 460

PLACEHOLDER

VOLTAGE: 575

PLACEHOLDER

UCC: 23 amps

PUMP: 73 amps

UCC: 20 amps

PUMP: 62 amps

UCC: 17 amps

PUMP: 38 amps

UCC: N/A amps

PUMP: 31 amps

UCC: N/A amps

PUMP: 24.5 amps

10 HP DRYER: 27 amps each

15 HP DRYER: 40 amps each

10 HP DRYER: 24 amps each

15 HP DRYER: 35 amps each

10 HP DRYER: 15 amps each

15 HP DRYER: 22 amps each

10 HP DRYER: 12 amps each

15 HP DRYER: 17 amps each

10 HP DRYER: 9.12 amps each

15 HP DRYER: 13.6 amps each

OPT. COLD CLIMATE:

14 amps

OPT. COLD CLIMATE:

12 amps

OPT. COLD CLIMATE:

10 amps

OPT. COLD CLIMATE:

n/a

OPT. COLD CLIMATE:

n/a

VOLTAGE: 208

UCC: 23 amps | PUMP: 73 amps

10 HP DRYER: 27 amps each

15 HP DRYER: 40 amps each

OPT. COLD CLIMATE: 14 amps

VOLTAGE: 230

UCC: 20 amps | PUMP: 62 amps

10 HP DRYER: 24 amps each

15 HP DRYER: 35 amps each

OPT. COLD CLIMATE: 12 amps

VOLTAGE: 380/415 (50 Hz)

UCC: 17 amps | PUMP: 38 amps

10 HP DRYER: 15 amps each

15 HP DRYER: 22 amps each

OPT. COLD CLIMATE: 10 amps

VOLTAGE: 460

UCC: N/A amps | PUMP: 31 amps

10 HP DRYER: 12 amps each

15 HP DRYER: 17 amps each

OPT. COLD CLIMATE: N/A amps

VOLTAGE: 575

UCC: N/A amps | PUMP: 24.5 amps

10 HP DRYER: 9.12 amps each

15 HP DRYER: 13.6 amps each

OPT. COLD CLIMATE: N/A amps

VOLTAGE: 208

UCC: 23 amps | PUMP: 73 amps

10 HP DRYER: 27 amps each

15 HP DRYER: 40 amps each

OPT. COLD CLIMATE: 14 amps

VOLTAGE: 230

UCC: 20 amps | PUMP: 62 amps

10 HP DRYER: 24 amps each

15 HP DRYER: 35 amps each

OPT. COLD CLIMATE: 12 amps

VOLTAGE: 380/415 (50hz)

UCC: 17 amps | PUMP: 38 amps

10 HP DRYER: 15 amps each

15 HP DRYER: 22 amps each

OPT. COLD CLIMATE: 10 amps

VOLTAGE: 460

UCC: N/A amps | PUMP: 31 amps

10 HP DRYER: 12 amps each

15 HP DRYER: 17 amps each

OPT. COLD CLIMATE: N/A amps

VOLTAGE: 575

UCC: N/A amps | PUMP: 24.5 amps

10 HP DRYER: 9.12 amps each

15 HP DRYER: 13.6 amps each

OPT. COLD CLIMATE: N/A amps

NOTE:

Specifications Subject to Change Without Notice. The decibel level of the dryer (measured

at 1.6 meters from the floor and 1 meter from the surface) is 94dB. The decibel level of the pump station (measured at 1.6 meters from the floor and 1 meter from the surface) is 94dB. Decibel levels are impacted by surrounding materials and conditions and will vary.
